Custom Electrical Cabinets
Custom Electrical Cabinets
SinoCemParts supplies custom electrical cabinets designed for power distribution, equipment control, and integrated industrial automation solutions.
SinoCemParts supplies custom electrical cabinets designed according to project requirements for power distribution, motor control, automation integration, and equipment protection. These cabinets can be configured for different control logic, operating environments, and installation needs in cement plants and industrial facilities.
With practical layout, reliable components, and maintenance-friendly design, SinoCemParts custom electrical cabinets help customers improve system integration, safety, and operational efficiency.
| Electric performance | |
|---|---|
| Rated insulation voltage | 690V(1000)V |
| Rated working voltage | 380V,400V,690V |
| Maximum working current of main bus | 6300A |
| Rated withstand current of main busbar | 100kA/1s |
| Main busbar rated peak withstand current | 220kA/0.1s |
| Maximum operating current of branch distribution bus (vertical bus) | 2000A |
| Peak current of distribution bus (vertical busbar): | |
| Standard type | 105kA(Max)/0.1s |
| Reinforced type | 176kA(Max)/0.1s |
| Protection level | IP41 |
